reaction to fire

QuadCore KS1000RW Roof Panels are classified B-s1,d0, when tested on the internal face of the product, according to the European Reaction to Fire classification system (Euroclasses) BS EN 13501–1: 2007+A1: 2009 under the certified name KS1000/2000 RW QuadCore and BS EN 13501-1:2018 under the certified name KS1000RW when using the following internal liners:

• CLEANsafe 15

• CLEANsafe 25

• CLEANsafe 55

• CLEANsafe120

• AQUAsafe 55

roof applications

QuadCore KS1000RW Roof Panels are tested to:

• Broof(t4) to BS EN 13501-5: 2016 under the certified name KS1000RW for panel thicknesses 40 - 150 mm and roof pitch of 0° - 10°

• Broof(t4) to BS EN 13501-5: 2016 under the certified name KS1000RW for panel thicknesses  40 - 150 mm and roof pitch of >10°Fire Resistance

fire resistance

Fire resistance classifications are subject to panel thickness, orientation, method of assembly, and steel coating. Please contact

for project specific details.

​

insurer approvals

QuadCore KS1000RW Roof Panels are tested to:

LPS 1181 Part 1: Issue 1.2 Requirements and tests for built-up cladding and sandwich panel systems for use as the external envelope of buildings certified to:

• LPS 1181-1 Grade EXT-B under the certified name QuadCore KS1000RW (Roof Panel) for thicknesses 40 - 150 mm.

• FM 4471 approval standard for class 1 roof panels under the certified name KS1000 RW for thicknesses 73 – 150 mm

• FM 4880 approval standard for class 1 fire rating of building panels or interior finish materials under the certified name KS1000 RW for thicknesses 40 – 150 mm

• FM 4882 approval standard for class 1 interior wall and ceiling materials or systems for smoke sensitive occupancies under the certified name KS1000 RW for thicknesses 40 – 150 mm


Insurer approvals are large scale testing regimes that provide objective third-party testing, which is underpinned by quarterly, bi-annual and annual factory surveillance audits (depending on the region) to verify compliance. Insurer approvals are subject to panel thickness, cover width, orientation, method of assembly, steel coating and manufacturing facility.​

​
